CUADRO: Arcadex Comp Disc Brake Specification: Flat Mount 140/160 Bottom Braket Standard: PressFit 86.5 X Ø41 Rear Axle: thru12 OLD (Over-Locknut-Dimension): 142 mm Front Derailleur:Non Compatible Rear Derailleur: SRAM UDH Hanger type Max Chainring Compatibility:

HORQUILLA: Bianchi Arcadex Fork Disc Brake Specification: Flat Mount 140/160 Front Axle: thru12 OLD (Over-Locknut-Dimension): 100 mm Tire Clearance: ETRTO 622-42mm Steer tube Diameter: 1 1/8"" Material: Epoxy - SM Carbon Fiber Composite

DIRECCIÓN: Bianchi Custom Acros ICR (Internal Cable Rounting) Spacers:5 mm x1, 10mm x3 Headtube Cover: Bianchi Costum Compresion Ring: 1.125 Inch Top Bearing: Angular contact Bearing 42x52x7 + seal Bottom Bearing: Angular contact Bearing 40x52x7 + seal

CAMBIO: Shimano GRX 822 RD-RX822, SGS Maximum Cassette Sprocket 51T

MANETAS: Shimano GRX 610 ST/BL-RX610

PLATOS: Shimano GRX 610 FC-RX610-1, 40T Crank Length: 170mm-XS(47)-SM(51)

PEDALIER: Shimano SM-BB72-41B, press fit

CADENA: Shimano CN-M7100

CASSETTE: Shimano CS-M7100-12 speed, 11-51T Driver body Interface: MicroSpline

FRENOS: Shimano Hydraulic Brake, BR-RX400

DISCOS: Shimano SM-RT70 IceTech Hub Interface: Centerlock Rotor Diameter: 160 mm (front&Rear)

RUEDAS: Fulcrum RapidRed 900 2-Way Fit Ready (for clincher and tubeless ready) Rim Diameter: 700C Material: Aluminum Alloy Rim Height: 24 mm Inner Wigth Channel: 22 mm

CUBIERTAS: Pirelli Cinturato™ GRAVEL M Classic, 45-622 tan sidewall

POTENCIA: Velomann AICR Alloy Rise: -2° Steerer Diameter: 1-1/8"" (28.6mm) HB interface Diameter: 1-1/4"" (31.8mm) Stem Lengths: 90mm - SM(51)

MANILLAR: Velomann Gravel ICR Alloy Flare: 16° Drop: 130mm Reach 70mm Interface Diameter: 1 1/4"" (31.8mm) HandleBar Widths: 400 - SX(47) SM(51)

CINTA MANILLAR: Bianchi Hexagon tape 2.5mm thickness, Full black

TIJA DE SILLÍN: Velomann Carbon UD SeatPost O.D: Ø27.2 mm Seatpost lengths: 350mm- SM(51)

SILLÍN: Velomann MITORA 149 H2 cover: soft touch, padding: foam, shell: nylon carbon rails: Steel lenght: 250mm width: 149mm


*Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
